Process Management: Creation, States, PCB, IPC, and Deadlocks

TAKEAWAYS:

• A process is an executing program instance with its own memory space, state, and resources, while a program is a static file on disk.
• Processes cycle through 5 states (New → Ready → Running → Waiting → Terminated) managed by the OS scheduler.
• The Process Control Block (PCB) is a kernel data structure storing process metadata (PID, registers, state, memory pointers) for context switching.
• Inter-Process Communication (IPC) enables processes to share data via pipes, message queues, shared memory, or semaphores (e.g., Pathao’s ride allocation uses semaphores to avoid double-booking).
• Deadlocks occur when processes hold resources waiting for others in a circular chain; the Banker’s Algorithm prevents them by checking system safety.
• Synchronization tools like mutexes and semaphores prevent race conditions (e.g., eSewa’s transaction locks ensure no duplicate payments).

1. Process vs. Program

A program is a passive collection of instructions stored on disk (e.g., notepad.exe). A process is an active execution of that program with:

• Its own memory space (code, data, stack, heap).
• Process ID (PID) assigned by the OS.
• State (running, waiting, etc.).
• Resources (open files, sockets, CPU time).

A program is a file; a process is a running instance with memory and state. (Image: Trara123 Hooman Mallahzadeh Cburnett, CC BY-SA 4.0, via Wikimedia Commons)

2. Process States and Lifecycle

A process transitions through 5 states (extended from the 3-state model):

stateDiagram-v2
    [*] --> New: Creation
    New --> Ready: Loaded into memory
    Ready --> Running: CPU allocated
    Running --> Waiting: Blocked (e.g., I/O)
    Waiting --> Ready: I/O completes
    Running --> Terminated: Execution ends
    Terminated --> [*]: Exit

Key Transitions:

• New → Ready: Process loaded into memory (e.g., when you launch Chrome).
• Ready → Running: Scheduler picks the process (e.g., Pathao’s ride-matching algorithm switches between drivers and riders).
• Running → Waiting: Process blocked (e.g., waiting for user input or disk I/O).
• Terminated: Process exits (e.g., a closed browser tab).

Worked Example: Consider a Ncell call center system where:

• New: A new call arrives (process created).
• Ready: Call waits in a queue (ready state).
• Running: Agent picks up the call (running state).
• Waiting: Agent checks customer details (blocked on database query).
• Terminated: Call ends (process exits).

3. Process Control Block (PCB)

The PCB is the OS’s record of a process, containing:

Why it matters:

• Enables context switching (saving/restoring CPU state when processes run).
• Used by the scheduler to decide which process runs next.

Example: When you switch between Daraz and WhatsApp, the OS saves WhatsApp’s PCB (registers, memory) and loads Daraz’s PCB.

4. Process Creation and Termination

Creation:

• Fork() (Unix/Linux): Creates a child process (e.g., bash -c "ls | grep .txt").
• Exec(): Replaces a process’s memory with a new program (e.g., launching notepad).
• Spawn() (Windows): Combines fork + exec.

Termination:

• Normal exit: Process calls exit() (e.g., closing a browser tab).
• Abnormal exit: Crash or abort() (e.g., a frozen app).
• Parent termination: Child processes are orphaned (adopted by init in Linux).
• Parent waits: wait() system call ensures parent cleans up child resources.

5. Inter-Process Communication (IPC)

Processes communicate via:

Semaphore Example (Mutex):

sequenceDiagram
    participant P1
    participant P2
    participant Semaphore
    P1->>Semaphore: request(lock)
    Semaphore-->>P1: grant
    P2->>Semaphore: request(lock)
    Semaphore-->>P2: wait (blocked)
    P1->>Semaphore: release(lock)
    Semaphore-->>P2: grant

Real-world tie:

• eSewa’s payment system uses semaphores to ensure only one process updates the transaction ledger at a time (prevents race conditions).

6. Process Synchronization

Race Condition:

When two processes access shared data simultaneously, leading to inconsistent results (e.g., two drivers claiming the same Pathao ride).

Solutions:

1. Mutex (Mutual Exclusion):
   • Only one process can access critical section at a time.
   • Example: Locking a bank account for a transfer.
2. Semaphores:
   • Generalized mutex (can allow multiple processes, e.g., semaphore = 3 allows 3 processes).
   • Used in NTC’s router queues to limit concurrent connections.
3. Monitors:
   • High-level construct with condition variables (e.g., Java’s synchronized blocks).

Worked Example (Dining Philosophers):

stateDiagram-v2
    [*] --> Hungry: Waits for fork
    Hungry --> Thinking: Eats (releases forks)
    Thinking --> Hungry: Drops fork

Deadlock Scenario: If all 5 philosophers take left forks first, they starve (circular wait).

7. Deadlocks

Necessary Conditions for Deadlock:

1. Mutual Exclusion: At least one resource held in non-sharable mode.
2. Hold and Wait: Process holds a resource and waits for another.
3. No Preemption: Resources cannot be forcibly taken.
4. Circular Wait: Circular chain of processes (P1 → P2 → P3 → P1).

Deadlock Detection (Resource Allocation Graph - RAG):

Cycle in RAG → Deadlock possible.

Prevention Strategies:

Banker’s Algorithm (Avoidance):

Worked Example: Suppose:

• Resources: 3 printers (total).
• Processes:
  • P1: Needs 2 (holds 0).
  • P2: Needs 1 (holds 1).
  • P3: Needs 2 (holds 1).

Allocation Matrix:

Available Resources: 1 Safe Sequence Check:

1. P2 can run (needs 0) → releases 1 → Available = 2.
2. P1 can run (needs 2) → releases 2 → Available = 4.
3. P3 can run (needs 1) → releases 1 → Available = 5. → System is safe.

Unsafe Scenario: If P1 requests 2 more (Available = 0), the system is unsafe (no process can run).

8. Starvation vs. Deadlock

In the Real World

1. eSewa’s Transaction Queue (IPC + Synchronization):

   • Uses message queues to handle payment requests.
   • Semaphores ensure only one process updates the ledger (prevents double-spending).
   • Worked Example: If 100 users pay simultaneously, semaphores serialize access to the database.

2. NTC’s Router Process Scheduling:

   • Routers manage multiple processes (forwarding, routing tables, error handling).
   • CPU scheduling (e.g., Round Robin) ensures fair packet forwarding.
   • Deadlock Prevention: Routers use timeouts for TCP connections to avoid indefinite blocking.

3. Daraz’s Order Fulfillment (Process States):

   • New: Order placed.
   • Ready: Awaiting warehouse pickup.
   • Running: Shipped to courier.
   • Waiting: Delivered but not signed.
   • Terminated: Order completed or canceled.
   • Synchronization: Mutexes lock inventory counts to prevent overselling.

Exam Tip

1. Diagrams are Mandatory:

   • Always draw the 5-state process model or RAG for deadlock questions.
   • Label transitions clearly (e.g., "Blocked → Ready on I/O completion").

2. Banker’s Algorithm:

   • For safety checks, simulate each process running and update available resources.
   • If a sequence exists where all processes complete → safe.

3. Deadlock Conditions:

   • Memorize the 4 conditions and how to break them (e.g., "Preemption" = forcibly take resources).
   • Starvation is often tested with priority scheduling (e.g., "Why does a low-priority process never run?").

4. IPC Examples:

   • Link real apps (eSewa, Pathao) to IPC methods (semaphores, pipes) in answers.
   • Example: "eSewa uses semaphores to synchronize payment processing."

5. PCB Focus:

   • Know the fields in a PCB (PID, registers, memory pointers) and why they’re needed for context switching.

6. Worked Examples:

   • For scheduling (FIFO, SRTF, RR), calculate turnaround time step-by-step:
     • Turnaround Time (TAT) = Completion Time − Arrival Time.
     • Waiting Time = TAT − Burst Time.
   • Example:

     Process	Arrival	Burst	FIFO TAT	FIFO Wait
     P1	0	8	8	0
     P2	1	5	13	8
     P3	2	10	23	13

Final Note: Process management is the heart of OS design. Focus on:

• States and transitions (draw them).
• PCB structure (what’s stored?).
• Deadlock conditions (how to detect/prevent).
• Real-world ties (eSewa, Pathao, NTC).
