HTTP Protocol, JSON & Advanced HTML Elements

TAKEAWAYS:

• HTTP is a stateless, client-server protocol using methods (GET, POST, etc.) and status codes (200, 404, 500) to exchange data over port 80/443.
• JSON is a lightweight text-based format for structured data (key-value pairs, arrays) used in APIs like REST and WebSockets.
• Advanced HTML5 elements (<canvas>, <audio>, <video>) enable interactive media without plugins, while semantic tags (<header>, <article>) improve accessibility and SEO.
• HTTP headers (e.g., Content-Type, Authorization) control request/response behavior, and CORS manages cross-origin resource sharing.
• Exam tip: Always include doctype declaration, proper indentation, and comments in code submissions. Use real-world examples (e.g., eSewa API calls) to justify answers.

1. HTTP Protocol: The Backbone of Web Communication

HTTP (HyperText Transfer Protocol) is the foundation of data exchange on the web. It operates on a request-response model between clients (browsers, apps) and servers.

sequenceDiagram
    participant Client as Browser
    participant Server as eSewa API
    Client->>Server: POST /api/payment (JSON Body)
    Server-->>Client: HTTP/1.1 200 OK (Transaction ID)
    Client->>Server: GET /api/status (Transaction ID)
    Server-->>Client: HTTP/1.1 200 OK (Payment Confirmed)
    Note right of Server: Status codes: 200 (Success), 401 (Unauthorized), 500 (Server Error)

Key Concepts

1.1 HTTP Methods (Verbs)

HTTP defines methods to perform actions on resources (URLs). The most common are:

Worked Example: eSewa Payment Flow When you pay a bill via eSewa, the app sends:

POST /api/payment HTTP/1.1
Host: esewa.com.np
Content-Type: application/json
Authorization: Bearer <token>

{
  "amount": 500,
  "phone": "98XXXXXXXX",
  "service": "electricity"
}

The server responds with:

HTTP/1.1 200 OK
Content-Type: application/json

{
  "status": "success",
  "transactionId": "ESW123456",
  "url": "https://esewa.com.np/payment/ESW123456"
}

Visual: HTTP Request-Response Cycle

sequenceDiagram
    Client->>Server: GET /home (HTTP Request)
    Server-->>Client: HTTP/1.1 200 OK (HTML Response)
    Client->>Server: POST /login (Form Data)
    Server-->>Client: HTTP/1.1 302 Redirect (Session Cookie)

1.2 HTTP Status Codes

Servers use status codes to indicate success/failure. Critical ones for exams:

Real-World Example: Daraz Order Status When you check your Daraz order, the API returns:

HTTP/1.1 200 OK
{
  "orderId": "DAR12345",
  "status": "shipped",
  "trackingUrl": "https://daraz.com.np/track/DAR12345"
}

If the order doesn’t exist:

HTTP/1.1 404 Not Found
{
  "error": "Order not found"
}

1.3 HTTP Headers

Headers provide metadata for requests/responses. Key ones:

• Content-Type: Defines data format (application/json, text/html).
• Authorization: For authentication (e.g., Bearer <token>).
• Cookie/Set-Cookie: Session management (e.g., PHPSESSID).
• CORS: Cross-Origin Resource Sharing (e.g., Access-Control-Allow-Origin: *).

Example: WhatsApp Web Login

1. Browser sends:

   GET /auth HTTP/1.1
   Host: web.whatsapp.com
   Origin: https://web.whatsapp.com


2. Server responds with:

   HTTP/1.1 200 OK
   Access-Control-Allow-Origin: https://web.whatsapp.com
   Set-Cookie: qr=abc123; Secure; HttpOnly


1.4 HTTP vs. HTTPS

How HTTPS secures data between client and server (Image: Fleshgrinder and The People from The Tango! Desktop Project., Public domain, via Wikimedia Commons) (Search: "TLS handshake diagram" for a real flow of SYN, ClientHello, ServerHello, etc.)

2. JSON: The Universal Data Format

JSON (JavaScript Object Notation) is a lightweight, text-based format for structured data. It’s used in:

• APIs (REST, GraphQL)
• Configuration files
• NoSQL databases (MongoDB)

JSON Syntax Rules

1. Data Types:
   • Strings ("name"), numbers (42), booleans (true/false), null, arrays ([1, 2, 3]), objects ({}).
2. Structure:
   • Key-value pairs in double quotes ("key": value).
   • Commas separate items ([1, 2, 3]).
   • No trailing commas.

Valid JSON Example:

{
  "user": {
    "id": 101,
    "name": "Ramesh Adhikari",
    "hobbies": ["coding", "hiking"],
    "isActive": true
  }
}

JSON vs. XML

Worked Example: NEPSE Stock API When you check NEPSE stock prices via an API, the response might be:

{
  "symbol": "NEPSE",
  "price": 2100.50,
  "change": -12.30,
  "time": "2023-11-15T14:30:00"
}

Parsing JSON in JavaScript

// Example: Fetch and parse JSON from an API
fetch('https://api.esewa.com.np/balance')
  .then(response => response.json()) // Parse JSON
  .then(data => {
    console.log("Balance:", data.balance);
    document.getElementById("balance").textContent = data.balance;
  })
  .catch(error => console.error("Error:", error));

3. Advanced HTML5 Elements

HTML5 introduced semantic tags and media elements to improve structure and interactivity.

3.1 Semantic HTML5 Tags

Improve SEO and accessibility by describing content meaningfully.

Example: TU Exam Portal Structure

<!DOCTYPE html>
<html>
<head>
  <title>TU Exam Results</title>
</head>
<body>
  <header>
    <h1>Tribhuvan University</h1>
    <nav>
      <a href="/results">Results</a>
      <a href="/schedule">Exam Schedule</a>
    </nav>
  </header>
  <main>
    <article>
      <h2>CSIT 5th Sem Results 2023</h2>
      <p>Published on 15 Nov 2023.</p>
    </article>
  </main>
  <footer>
    <p>© 2023 TU. <a href="mailto:[email protected]">Contact</a></p>
  </footer>
</body>
</html>

3.2 Media Elements

Canvas API

Draw graphics dynamically using JavaScript. Used in:

• Games (e.g., Flappy Bird)
• Data visualization (charts)
• Interactive diagrams

Example: Drawing a Rectangle

<canvas id="mycanvas" width="300" height="200"></canvas>
<script>
  const canvas = document.getElementById("mycanvas");
  const ctx = canvas.getContext("2d");
  ctx.fillStyle = "blue";
  ctx.fillRect(10, 10, 100, 50); // (x, y, width, height)
</script>

(Search: "HTML5 Canvas API reference diagram")

Audio/Video Elements

Embed media without plugins (e.g., Flash).

Example: Playing a Sound

<audio id="alertSound" src="alert.mp3" preload="auto"></audio>
<script>
  document.getElementById("alertSound").play();
</script>

Example: YouTube-like Video Player

<video width="400" controls>
  <source src="lecture.mp4" type="video/mp4">
  Your browser does not support HTML5 video.
</video>

Geolocation API

Access user location (with permission). Used in:

• Pathao: Showing rider locations.
• Google Maps: Directions.

Example: Get User Location

if (navigator.geolocation) {
  navigator.geolocation.getCurrentPosition(
    position => {
      console.log("Latitude:", position.coords.latitude);
      console.log("Longitude:", position.coords.longitude);
    },
    error => console.error("Error:", error)
  );
}

4. HTTP in Real-World Applications

Example 1: eSewa API Calls

When you pay a bill, eSewa’s frontend sends:

1. POST to /api/initiate-payment (with amount, phone, service).
2. Server responds with a QR code URL (200 OK).
3. After payment, POST to /api/confirm-payment (with transaction ID).
4. Server returns receipt (200 OK) or failure (402 Payment Required).

Example 2: Daraz Order Processing

1. You place an order → POST to /api/orders (with cart items).
2. Daraz checks stock → GET to /api/inventory.
3. If stock is available → 201 Created (order confirmed).
4. If out of stock → 400 Bad Request (error message).

Example 3: NTC Electricity Bill

When you check your NTC bill online:

1. Browser sends GET to https://ntc.gov.np/api/bill?customerId=12345.
2. Server responds with:

   {
     "customer": "Ramesh Adhikari",
     "billAmount": 1250,
     "dueDate": "2023-12-15",
     "paymentUrl": "https://ntc.gov.np/pay/12345"
   }


3. If the customer ID is invalid → 404 Not Found.

5. Common Exam Questions & Solutions

Question 1: Create a Canvas with a Div

Answer:

<!DOCTYPE html>
<html>
<head>
  <title>Canvas Example</title>
</head>
<body>
  <div id="dv1">
    <canvas id="mycanvas" width="300" height="200"></canvas>
  </div>
  <script>
    const canvas = document.getElementById("mycanvas");
    const ctx = canvas.getContext("2d");
    ctx.fillStyle = "green";
    ctx.fillRect(50, 50, 100, 100);
  </script>
</body>
</html>

Question 2: HTTP Request for a Bank Loan

Scenario: You submit a loan application to NMB Bank via their website. Request:

POST /api/loans HTTP/1.1
Host: nmb.com.np
Content-Type: application/json
Authorization: Bearer abc123

{
  "customerId": "CUST456",
  "amount": 500000,
  "tenure": 5,
  "purpose": "business"
}

Response (Approved):

HTTP/1.1 201 Created
Content-Type: application/json

{
  "loanId": "LOAN789",
  "status": "approved",
  "interestRate": 8.5,
  "emi": 10245,
  "disbursementDate": "2023-12-01"
}

Response (Rejected):

HTTP/1.1 400 Bad Request
{
  "error": "Insufficient credit score",
  "suggestions": ["Improve score by paying bills on time"]
}

Question 3: JSON to XSD Conversion

Given JSON:

{
  "student": {
    "id": "CSIT123",
    "name": "Sita Thapa",
    "courses": ["Web Tech", "DBMS"]
  }
}

Equivalent XSD:

<xs:schema xmlns:xs="http://www.w3.org/2001/XMLSchema">
  <xs:element name="student">
    <xs:complexType>
      <xs:sequence>
        <xs:element name="id" type="xs:string"/>
        <xs:element name="name" type="xs:string"/>
        <xs:element name="courses">
          <xs:complexType>
            <xs:sequence>
              <xs:element name="course" type="xs:string" maxOccurs="unbounded"/>
            </xs:sequence>
          </xs:complexType>
        </xs:element>
      </xs:sequence>
    </xs:complexType>
  </xs:element>
</xs:schema>

Exam Tip

1. For HTTP Questions:

   • Always include method, headers, and status code in answers.
   • Use real-world examples (e.g., "When you log in to eSewa, the server responds with a 302 Redirect to set a session cookie").
   • Mention CORS if cross-origin requests are involved.

2. For JSON Questions:

   • Validate syntax (e.g., "key": value with double quotes).
   • Show how to parse JSON in JavaScript (response.json()).

3. For HTML5 Questions:

   • Use semantic tags (<header>, <article>) for structure.
   • For <canvas>, include JavaScript to draw shapes.
   • For forms, validate client-side (JavaScript) and server-side (PHP).

4. Code Formatting:

   • Indentation: Use 2-4 spaces for readability.
   • Comments: Add // or /* */ to explain logic.
   • Doctype: Always declare <!DOCTYPE html> at the top.

Final Note: HTTP and JSON are the unsung heroes of web apps. Master them, and you’ll ace questions on APIs, data exchange, and dynamic content. Practice with eSewa, Daraz, and NEPSE APIs to see real-world HTTP/JSON in action!

In the real world

• eSewa/Khalti: Uses POST HTTP method with JSON payloads for secure transactions (e.g., {"amount":500,"phone":"98XXXXXXXX"}) and returns 200 OK with transaction details or 401 Unauthorized if authentication fails.
• Daraz: Implements GET requests for product listings (e.g., GET /products?category=electronics) and returns JSON with 200 OK status, while 404 Not Found appears if the product is unavailable.
• WhatsApp Web: Relies on CORS headers (Access-Control-Allow-Origin) to allow cross-origin requests from web.whatsapp.com to the WhatsApp server, enabling seamless login and message sync.
