Memory Management: Allocation, Partitioning, Paging, Segmentation & Swapping

Core Concepts: Why Memory Management Matters

The OS must allocate memory to processes efficiently while ensuring:

1. No process overwrites another’s memory (protection).
2. No process hogs all memory (fairness).
3. Memory is used optimally (minimize fragmentation).
4. Processes can share memory safely (e.g., libraries, threads).

stateDiagram-v2
    [*] --> MemoryAllocation: OS starts
    MemoryAllocation --> Contiguous: First-fit/Best-fit/Worst-fit
    MemoryAllocation --> NonContiguous: Paging/Segmentation
    Contiguous --> ExternalFragmentation: Over time
    NonContiguous --> InternalFragmentation: Page/Segment size mismatch
    ExternalFragmentation --> Compaction: Rare in modern OS
    InternalFragmentation --> TLB: Reduces page-table lookups
    [*] --> Swapping: Move processes to disk

1. Memory Allocation Strategies

A. Contiguous Memory Allocation

Processes are loaded into contiguous blocks of memory. Three schemes:

Worked Example: First-Fit Allocation

Memory blocks (in KB): 100, 500, 200, 300, 600 Process sizes (in KB): 212, 417, 112, 426 Steps:

1. Process 212KB: Fits in 500KB → Allocate 500KB (remaining: 288KB).
2. Process 417KB: Fits in 600KB → Allocate 600KB (remaining: 183KB).
3. Process 112KB: Fits in 200KB → Allocate 200KB (remaining: 88KB).
4. Process 426KB: No block left ≥426KB → Failure.

Gantt Chart:

| Process 212 | Process 417 | Process 112 | --- |
| 100KB       | 500KB       | 200KB       | 300KB, 600KB unused

Real-World Tie-In:

• eSewa’s server memory: Uses best-fit to allocate memory for thousands of concurrent transactions. A poorly sized block (e.g., 512MB for a 400MB process) wastes RAM, increasing costs.

B. Non-Contiguous Allocation

Solves external fragmentation by dividing memory into fixed-size pages or variable-size segments.

1. Paging

• Divide memory into fixed-size frames (e.g., 4KB).
• Divide processes into pages of same size.
• Page Table: Maps logical pages → physical frames.

Key Components:

• Page Table Entry (PTE): Contains frame number + flags (valid/invalid, read/write).
• TLB (Translation Lookaside Buffer): Cache for recent page-table lookups (reduces RAM access).
• Page Fault: When a process accesses an invalid page → OS loads it from disk (swap space).

Worked Example: Page Table Process size: 12KB, Page size: 4KB → 3 pages (P0, P1, P2). Physical memory frames: 8 frames (0–7). Page Table:

Accessing Address 0x1C00 (5KB):

1. Divide by page size: 0x1C00 / 4KB = P1.
2. Check TLB → Not found.
3. Look up page table → P1 → Frame 6.
4. Add offset (0x1C00 % 4KB = 0x1000) → Physical address: Frame 6 * 4KB + 0x1000.

Real-World Tie-In:

• WhatsApp’s backend: Uses paging to handle millions of messages. A page fault (e.g., loading a user’s chat history from disk) causes a delay if the TLB misses.

2. Segmentation

• Divide memory by logical segments (code, data, stack, heap).
• Segment Table: Maps segment number → base address + limit.

Advantages:

• Natural fit for programs (e.g., separate code/data).
• Protection: Each segment has its own base/limit registers.

Disadvantages:

• External fragmentation (gaps between segments).
• Complexity: Segment table lookups slower than paging.

Real-World Tie-In:

• Banking systems (e.g., NMB Bank): Use segmentation to isolate transaction logs (data), executable code, and user sessions. A crash in one segment (e.g., a corrupted transaction) doesn’t affect others.

2. Memory Protection and Sharing

A. Base and Limit Registers

• Base Register: Starting address of a segment/page.
• Limit Register: Maximum size of the segment/page.
• Check: For any access, verify: logical_address ≤ limit and physical_address = base + logical_address.

Example:

• Segment: Code (base=0x1000, limit=8KB).
• Access: Address 0x2FFF (7KB). 0x2FFF - 0x1000 = 0x1FFF (7KB) ≤ 8KB → Valid. 0x2FFF - 0x1000 = 0x3000 (12KB) > 8KB → Segmentation Fault.

B. Shared Memory

• Shared Code: Libraries (e.g., libc.so) loaded once in memory.
• Shared Data: Databases (e.g., MySQL tables) or IPC (Inter-Process Communication).

Example:

• Daraz’s order processing: Multiple worker processes share the same "inventory database" segment in memory to avoid redundant copies.

3. Swapping and Thrashing

A. Swapping

• Move entire processes to disk (swap space) when RAM is full.
• Steps:
  1. OS selects a process to swap out (e.g., least recently used).
  2. Save its pages to disk.
  3. Load another process into RAM.

Real-World Tie-In:

• NTC’s traffic monitoring system: During peak hours, the OS swaps out less critical processes (e.g., historical data analysis) to prioritize real-time traffic updates.

B. Thrashing

• Problem: OS spends more time swapping than executing processes.
• Cause: Insufficient RAM → too many page faults.
• Solution: Increase RAM or use working set model (keep only actively used pages in RAM).

Example:

• Pathao’s driver app: If the OS thrashes while matching drivers to rides, the app becomes unresponsive.

4. Memory Hierarchy

Key Idea: Locality of Reference (programs access a small subset of memory repeatedly).

• Temporal Locality: Recently used data will be used again (e.g., loop variables).
• Spatial Locality: Nearby data is often used (e.g., array traversal).

In the Real World

1. eSewa’s Payment System

   • Idea Used: Paging + Memory Protection
   • How: Each transaction is processed in a separate page. If a user tries to access another user’s data (e.g., 0x8000 → 0x9000), the OS checks the page table and denies access (segmentation fault). This prevents fraud.

2. Daraz’s Order Queue

   • Idea Used: First-Fit Memory Allocation
   • How: When a new order arrives, Daraz’s backend allocates the first available memory block ≥ order size. If no block fits (e.g., a 512MB order on a 480MB block), the order is delayed until memory is freed.

3. Ncell’s Billing Server

   • Idea Used: Shared Memory + Segmentation
   • How: The billing system uses shared memory for customer databases (e.g., segment 0x2000–0x3FFF). Multiple processes (e.g., update_bill(), generate_receipt()) access the same segment without duplication, reducing RAM usage.

Exam Tip

What Examiners Love to Test

1. Memory Allocation Schemes

   • Do: Draw Gantt charts for first-fit/best-fit. Compare pros/cons in a table.
   • Avoid: Memorizing exact numbers—focus on trends (e.g., "best-fit reduces fragmentation").

2. Paging vs. Segmentation

   • Do: Explain why paging avoids external fragmentation (fixed-size pages) vs. segmentation (variable-size gaps).
   • Avoid: Confusing page tables with segment tables. Page tables map logical → physical addresses; segment tables map segment numbers → base addresses.

3. Page Fault Handling

   • Do: Trace a page fault step-by-step:
     1. CPU generates logical address.
     2. TLB miss → page table lookup.
     3. Invalid page → OS loads from disk.
     4. Update page table + TLB.
   • Avoid: Forgetting to mention swap space or TLB.

4. Real-World Applications

   • Do: Link concepts to eSewa (memory protection), Daraz (allocation), or Ncell (shared memory).
   • Avoid: Generic answers like "used in computers." Be specific!

5. Short Notes (2×5 Marks)

   • Memory Hierarchy: Draw the pyramid and explain locality of reference.
   • Thrashing: Define as "high page fault rate → poor CPU utilization" + solution (increase RAM or working set model).

Common Pitfalls

• Assuming all OS use paging: Some embedded systems (e.g., routers) use contiguous allocation for simplicity.
• Ignoring TLB: Always mention it in paging questions—it’s critical for performance!
• Confusing swapping and paging: Swapping moves whole processes; paging moves individual pages.
• Forgetting protection: Every allocation scheme must ensure processes can’t access arbitrary memory.

Practice Questions (Self-Check)

1. Given memory blocks [100, 500, 200, 300] and processes [212, 417, 112, 426], which allocation scheme works best? Why?

   • Answer: Best-fit (allocates 500 → 212, 600 → 417, 200 → 112; 426 fails in all schemes).

2. How does WhatsApp reduce page faults when loading chats?

   • Answer: Preloads frequently accessed chats into RAM (temporal locality) and uses a large TLB to cache page-table entries.

3. Why can’t segmentation alone solve external fragmentation?

   • Answer: Segments are variable-sized → gaps between them grow over time (e.g., free blocks of 50KB, 30KB, 20KB can’t fit a 100KB process).

A close-up of DDR4 RAM sticks showing slots, pins, and heat spreaders. (Image: ElooKoN, CC BY-SA 4.0, via Wikimedia Commons)
