Memory Management: Allocation, Fragmentation, Paging, Segmentation & Thrashing

Memory Management: Core Concepts

Why Memory Management?

The OS must allocate memory to processes efficiently while ensuring:

• No process overwrites another (protection).
• No process starves (fairness).
• Memory is used optimally (utilization).

stateDiagram-v2
    [*] --> MemoryAllocation: OS starts
    MemoryAllocation --> Allocate: Process requests memory
    Allocate --> Success: Memory granted
    Allocate --> Fail: Not enough memory
    Success --> Execute: Process runs
    Execute --> Release: Process finishes
    Release --> [*]

Dual-channel DDR4 sticks in a desktop motherboard (Image: Peter Fiskerstrand, CC BY-SA 4.0, via Wikimedia Commons)

Memory Allocation Strategies

1. Contiguous Allocation

Processes are allocated contiguous blocks of memory. Types:

• Fixed Partitioning: Memory divided into fixed-size blocks (e.g., 100KB, 500KB).
• Variable Partitioning: Blocks grow/shrink as processes arrive/depart.

Allocation Algorithms

Worked Example (First-Fit):

Partitions: [100, 500, 200, 300, 600] KB
Processes: 212KB, 417KB, 112KB, 426KB

1. 212KB: First fit → 500KB (remaining: 288KB).
2. 417KB: Next fit → 600KB (remaining: 183KB).
3. 112KB: First fit → 200KB (remaining: 88KB).
4. 426KB: No block left → FAIL.

2. Non-Contiguous Allocation

Solves fragmentation by dividing memory into small fixed-size blocks (paging) or logical segments (segmentation).

A. Paging

• Divide memory into fixed-size frames (e.g., 4KB).
• Processes divided into pages (same size as frames).
• Page Table maps virtual pages → physical frames.

Advantages: ✔ No external fragmentation. ✔ Faster allocation (direct frame mapping).

Disadvantages: ✖ Internal fragmentation (wasted space in last page). ✖ Page table overhead.

Real-World Use:

• eSewa App: When you pay bills, the OS uses paging to load different app modules (payment, profile, history) dynamically without crashing.

B. Segmentation

• Divide memory into variable-size segments (e.g., code, data, stack).
• Segment Table maps logical segments → physical memory.

Advantages: ✔ Logical separation (e.g., code vs. data). ✔ No internal fragmentation (segments fit exactly).

Disadvantages: ✖ External fragmentation (gaps between segments). ✖ Slower allocation (must search for contiguous space).

Comparison: Paging vs. Segmentation

Real-World Use:

• WhatsApp Desktop: Uses segmentation to load different parts of the app (chat window, status, calls) separately, allowing smooth switching without reloading everything.

Fragmentation Problems

1. External Fragmentation

• Definition: Free memory exists but is not contiguous (too small for new processes).
• Cause: Variable partitioning (e.g., after many allocations/deallocations).

Example (Segmentation):

Memory: [Used: 100KB][Free: 50KB][Used: 200KB][Free: 30KB][Used: 150KB]

• Total free = 80KB, but no single block ≥ 50KB → Process of 50KB fails!

Solution:

• Compaction: Shift processes to one end (expensive, pauses system).
• Paging/Segmentation: Avoids external fragmentation.

2. Internal Fragmentation

• Definition: Wasted space inside allocated blocks (e.g., last page of a process).
• Cause: Fixed-size allocation (paging).

Example (Paging):

• Page size = 4KB, process needs 3.5KB → 0.5KB wasted.

Solution:

• Use variable page sizes (complex).
• Accept as trade-off for no external fragmentation.

Virtual Memory

Why?

• Extend RAM with disk (secondary storage).
• Load only active pages (swap unused pages to disk).

How?

1. Page Fault: CPU accesses a page not in RAM → OS loads it from disk.
2. Page Replacement: If RAM full, evict a page (e.g., LRU, FIFO, Clock).

sequenceDiagram
    participant CPU
    participant OS
    participant RAM
    participant Disk
    CPU->>OS: Access Page X (not in RAM)
    OS->>Disk: Load Page X
    Disk-->>RAM: Page X loaded
    RAM-->>CPU: Page X ready
    Note over OS,Disk: Page Fault Handled

Real-World Use:

• Google Chrome: Uses virtual memory to run multiple tabs smoothly. If RAM runs low, inactive tabs are swapped to disk (slowing down but keeping the system responsive).

Thrashing

Definition

• Excessive page faults → CPU spends more time swapping than executing.
• Cause: Insufficient RAM for active processes.

Symptoms

• Low CPU utilization (always swapping).
• High disk I/O (constant page faults).

Solution

• Increase RAM.
• Reduce active processes (terminate some).
• Better page replacement (e.g., LRU).

Example (Ncell App Crash):

• If your phone runs too many apps (e.g., Facebook, YouTube, WhatsApp), the OS may thrash, causing apps to freeze or crash due to excessive swapping.

In the Real World

1. eSewa (Nepal)

   • Paging: When you pay an electricity bill, eSewa’s backend OS uses paging to load different modules (user login, payment processing, confirmation) without reloading the entire app.
   • Segmentation: The app’s code, data, and stack are stored in separate segments for security and efficiency.

2. Daraz (Nepal/E-commerce)

   • Memory Allocation: When you add items to your cart, Daraz’s server allocates memory dynamically using best-fit to ensure no process (e.g., order processing) starves.
   • Thrashing Prevention: Daraz’s servers use SSD storage to reduce page fault times, avoiding thrashing during Black Friday sales.

3. Ncell (Mobile Network)

   • Virtual Memory: Your phone’s OS uses virtual memory to run multiple apps (WhatsApp, Instagram, games) smoothly. If RAM is full, inactive apps are swapped to storage.
   • Fragmentation: Over time, memory fragmentation can slow down your phone. Ncell’s cloud services (e.g., backup) indirectly rely on efficient memory management to keep data accessible.

Exam Tip

What Examiners Want

1. Algorithms: Know how first-fit, best-fit, worst-fit work and when to use each. Always show step-by-step allocation in exams.
2. Fragmentation: Differentiate internal vs. external and explain solutions (compaction, paging).
3. Paging vs. Segmentation: Compare size flexibility, fragmentation, and use cases.
4. Virtual Memory: Explain page faults, replacement policies (LRU, FIFO), and thrashing.
5. Real-World Links: Relate concepts to eSewa, Daraz, or Ncell (e.g., "Daraz uses best-fit to avoid memory wastage during peak hours").

Common Mistakes to Avoid

❌ Assuming all algorithms are equally good (best-fit is slower but reduces waste). ❌ Ignoring internal fragmentation in paging (always mention it’s a trade-off). ❌ Forgetting to show steps in allocation examples (examiners want trace tables). ❌ Mixing paging and segmentation (paging = fixed, segmentation = variable).

Model Answer Structure

For a 5-mark question on allocation:

1. Define the algorithm (1 mark).
2. Show step-by-step allocation (2 marks).
3. Compare with other algorithms (1 mark).
4. Mention pros/cons (1 mark).

Example Answer (First-Fit):

First-fit allocates the first available memory block that can accommodate the process. For partitions [100, 500, 200, 300, 600] KB and processes [212, 417, 112, 426] KB:

1. 212KB → 500KB (remaining: 288KB).
2. 417KB → 600KB (remaining: 183KB).
3. 112KB → 200KB (remaining: 88KB).
4. 426KB → No block left (failure). Pros: Fast, simple. Cons: External fragmentation (e.g., 288KB + 88KB = 376KB free but unusable for a 400KB process).
